Advatech offers a broad range of CZT radiation detectors (Overview of CZT Detectors) - both counter and spectroscopy grade, available as sensors, assemblies and probes through to complete instruments. Standard products and bespoke configurations available.A range of Quasi-hemispherical Detectors are available.(What are Quasi-hemispherical Detectors?)


CZT is a room temperature semiconductor that directly converts radiation (x-ray or gamma-ray) photons into electrons and can produce >10⁶ photons/second/mm² with an effective Z of >49 and density 5.8g/cm³.









Typical energy resolution:    <6.5% @ 59.5keV

Count rate:                           1M cps/mm²

Standard arrays:                  4x4, 8x8, 1x16, 1x32











Operating voltages:           200 - 500V

Energy range:                    20keV - 1.5MeV

Energy resolution*:            >4% @ 59.5keV - Counter Grade

Energy resolution*:            7-15% @ 59.5keV - Discrimination Grade

Energy resolution*:            <7% @ 59.5keV - Spectrometer Grade

Standard Sizes:                 5x5x2mm, 10x10x2mm

* For size 5x5x2mm











Operating voltages:            200 - 1,000V

Energy range:                    50keV - 1.5MeV

Energy resolution:              <3% @ 59.5keV

Standard Size:                   4x4x2mm











Operating voltages:             1,000 - 3,000V

Energy range:                      50keV - 3MeV

Typical energy resolution:    <4% @ 59.5keV

Standard Sizes:                  10x10x5mm, 10x10x10mm











The following housed Quasi-hemispherical CZT Detectors are available:

Parameter

RIT-HD-500

RIT-HD-500S

RIT-HD-1500

CZT Sensor Volume (cm³)

0.5

0.5

1.5

Bias Voltage (V)

≤1,500

≤1,500

≤3,500

Energy Resolution - FWHM@662keV (keV)

≤30

≤18

≤30

Peak-to-Compton Ratio @662keV

≤2.3

≤4.0

≤2.5

Size - Enclosure (mm)

Ø22 x 33

Ø22 x 33

Ø32 x 36

Connector

BNC

BNC

SHV

Energy Range (keV)

 20 to 200

Operating Temperature (ºC)

0 to +40

CZT Radiation Detectors - Cadmium Zinc Telluride Radiation Detectors


CZT Detectors - Pixelated(P/N: IMD-PX)



CZT Detectors - Coplanar Grid(P/N: IMD-CG)



CZT Detectors - Planar-Type  (P/N: IMD-P)



CZT Detectors - Quasi-Hemispherical  (P/N: IMD-HD)



CZT Detectors - Housed Quasi-Hemispherical  (P/N: RIT-HD)
