Laser / Optical Properties

Units

Value

Laser Wavelengths

nm

1063

Emission Linewidth

nm

3

Absorption Band Peak

nm

807.5

Absorption Bandwidth

nm


Emission Cross-section (@1064nm)

10‾²º cm²

76

Fluorescent Lifetime (1.1% doping)

µs

100

Absorption Coefficient @808nm

cm‾¹

49

Intrinsic Loss @1064nm

cm‾¹

<0.003

Refractive Index (n) @ 1064nm


1.99

Thermal Optical Coeff. (dn/dT) @1060nm

 10‾⁶/ºC

4.7

Nd:GdVO4 Laser - Availability


Physical / Thermal Properties

Units

Value

Chemical Formula


 GdxNdxVO4

Melting Point

ºC

1780

Thermal Expansion Coeff. @20ºC

 10‾⁶/ºC

1.5

Thermal Conductivity Coeff. @20ºC

W/m/ºK

11.7

Specific Heat

 J/g K

0.79

Chemical Durability (@100ºC weigh loss rate distilled water)

μg/hr.cm²


Density

g/cm³

5.48

Durability Knoop Hardness

kgf/mm²


Mohs Hardness


4.6-5

Damage Threshold (1ns)

J/cm³


Nd:GdVO4 Laser Rod Properties













Neodymium:Gadolinium Vanadate (Nd:GdVO4) lases at a wavelength of 1063nm. Needing pumping at a wavelength of 807.5nm, Nd:GdVO4 is well suited to diode pumping. It has larger absorption and emission cross-sections than Nd:YAG is versatile and is used across a broad range of applications.


Key strengths of Nd:GdVO4:
