DKDP (often refered to as KD*P) Pockels Cells
DKDP (often refered to as KD*P) Pockels Cells are widely employed in high average power laser applications.

DKDP Pockels Cells offers the following features:
  • Broad transmission range: 200 - 2000nm
  • Low absorption
  • Minimal piezoelectric ringing
  • Compact sizes
  • High power capability
  • Good temperature stability
Request Quote
DKDP Pockels Cells / KD*P Pockels Cells - Properties
Advatech can supplying a range of high performance and ‘ready to use’ DKDP Pockels Cells with aperture of 2.5mm and 3.5mm.

Custom variants are possible.
Parameter Units Value
Aperture Diameter mm 2.5mm

3.5mm
Quarter-Wave Voltage kV 3.6

4.8
Intrinsic Contrast @1064nm >1000:1
Optical Transmission % >98
Repetition ratio kHz <100
Damage Threshold (1ns pulses) MW/cm2 >500
Damage Threshold (CW Power) kW/cm2 >3
Wavefront Distortion <λ/8
Capacitance (Typical) pF 3
Electrical Contacts Miniature
Banana Plus
Size:
Diameter mm 25.4
Length 50.7
