The following range of CZT radiation probe variants is available. Each probe contains a CZT quasi-hemispherical sensor coupled with a matched, low noise preamplifier. All are robustly housed and come complete with a cable and connector.









Part Number

Detector

Volume

(mm³)

Probe Size

(mm)

Conversion

Efficiency

(mV/keV)

Bias

Voltage

(V)

Energy

Resolution

FWHM@662keV

(keV)

Peak-to-Compton

Ratio

@662keV


RIT-310/Z/01

c.1.2

8.2Ø x 90

> 0.1

< 600

≤ 20

≤ 1.3

RIT-310/Z/05

c.5

8.2Ø x 90

> 0.1

< 600

≤ 22

≤ 1.6

RIT-310/Z/05S

c.5

8.2Ø x 90

> 0.1

< 600

≤ 10

≤ 2.5

RIT-310/Z/20

c.15

8.2Ø x 90

> 0.1

< 600

≤ 22

≤ 1.6

RIT-310/Z/20S

c.15

8.2Ø x 90

> 0.1

< 600

≤ 10

≤ 2.5

RIT-310/Z/60

c.55

8.2Ø x 90

> 0.1

< 600

≤ 25

≤ 1.8

RIT-310/Z/60S

c.55

8.2Ø x 90

> 0.1

< 600

≤ 15

≤ 2.5

RIT-311

0.5 ... 20

45 x 24 x 4

> 0.1

< 600

10 - 22

≤ 2.5

RIT-311/C*

0.5 ... 200

45 x 24 x 4

> 0.1

< 600

N/A

N/A

RIT-313

1 ... 10

6Ø  x 63

> 0.1

< 500

<22

≤ 2.5

RIT-500S

500

24Ø  x 58

> 0.2

< 1,500

<2.5

>4.0

RIT-1500

1500

32Ø  x 58

> 0.2

< 2,500

<3.5

>4.0

RIT-4000

4000

40Ø  x 58

> 0.1

< 3,000

<4.0

>4.0

DT-01A


17Ø x 79


< 500

<6.5% @ 59.5keV


DT-02A


30.5Ø x 67



<6.5% @ 59.5keV
