Medipix2/Timepix


Advatech UK supplies Medipix2/Timepix based detector products and technologies designed and manufactured by X-Ray Imatek.


The Medipix2/Timepix ASIC is the result of over a decade of development by a CERN led consortium. The ASIC, bonded with a sensor material (Silicon, Cadmium Telluride or Gallium Arsenide), together with interface/driver electronics and software is now available for integration into both academic research projects and commercial products.


To enable potential users to quickly become familiar with the capabilities of the Medipix2/Timepix technology, evaluation kits are now available:


Sensor

Units

Silicon

CdTe

GaAs

Thickness

µm

300 or 1,000

500 or 1,000

500 or 1,000

Energy Range

keV

4 - 25

40 - 120

20 - 90

Quantum Efficency


60%@15keV

85%@60keV

40%@60keV

Parameter

Units

Uno

Quatro

Pixel Size

µm

55 x 55

55 x 55

Sensitive Area

mm

14.1 x 14.1

28.2 x 28.2

Image Resolution

px

256 x 256

512 x 512

Dynamic Range


13-bit Depth

13-bit Depth

Frame Rate

fps

500

300

Key Parameters


Sensors/Parameters (Standard)


Features


Interface:              USB 2.0

Drivers:                 Windows XP/7, Linux

API Library:           Available

Software:              XRI Suite

Output Formats:   AVI, BMP, TIFF, Raw, PNG, ASCII

Size:                     172 x 138mm
