Laser / Optical Properties

Units

Value

Laser Wavelengths

nm

914, 1064,1342

Emission Linewidth

nm


Absorption Band Peak

nm

808

Absorption Bandwidth

nm

4

Emission Cross-section (@532nm)

10‾²º cm²

156

Fluorescent Lifetime (1.1% doping)

µs

90

Absorption Coefficient @808nm

cm‾¹

31.4

Refractive Index (nD) @ 589nm no/ne


1.957/2.165

Refractive Index (n) @ 1064nm


1.76

Nonlinear Index N2



Abbe Value



Thermal Opical Coeff. (dn/dT) @20ºC

 10‾⁶/ºC

8.5

Nd:YVO4 Laser - Availability


Physical / Thermal Properties

Units

Value

Chemical Formula


 YVO4:Nd

Melting Point

ºC

1825

Thermal Expansion Coeff. @20ºC

 10‾⁶/ºC

4.43/11.37

Thermal Conductivity Coeff. @20ºC

W/m/ºK

5.2

Specific Heat

 J/g K

0.59

Chemical Durability (@100ºC weigh loss rate distilled water)

μg/hr.cm²


Density

g/cm³

4.22

Durability Knoop Hardness

kgf/mm²


Mohs Hardness


5

Young's Modulus

10³  N/mm²


Poisson's Ratio



Damage Threshold (1ns)

J/cm³


Nd:YVO4 Laser Rod Properties













Neodymium:Yttrium Orthovanadate (Nd:YVO4) is one of the most efficient lasing media currently available. Nd:YVO4 lases at three wavelengths - 914nm, 1064nm and 1342nm.With a pumping wavelength of 808nm Nd:YVO4 is very well suited to diode-pumping.


Key strengths:
