Advatech Gamma Microspectrometer CZT
The Advatech MICRO-SPECT-C product is a modular family of compact, high performance gamma radiation spectrometers based of spectrometry grade CZT. These spectrometers are based around a compact Base Unit which include a miniature Multi-channel Analysers (MCA), USB-based PC interfaces and easy-to-use Windows software. This Base Unit can be used with a number of CZT Sensors which vary in size and format.

Gamma spectrometers based on a CsI(Tl) scintillator (MICRO-SPECT-S) are also available.
MICRO-SPECT-C Base Unit
The MICRO-SPECT-C Base Unit has parameters are as follows:
Processor: Multi-channel Analyser (MCA)
Channels: 2k (Standard) or 16k (Plus)
Throughput (max.): 100 kcps
Shaping Time: Standard: 0.1 to 2µs, 0.1us steps
Plus: 0.1 to 25.5µs, 0.1µs steps
Flat Top Time: 0 to 15µs, 0.1µs step
PZC Adjustment: Automated
Size: 25 x 25 x 58mm
Weight: 80g
Power/Output: USB (4.5 to 5.2V, 100mA max.), Micro USB (Type A or B)
MICRO-SPECT-C Base UnitMICRO-SPECT-C Base Unit
MICRO-SPECT-C Sensor - Options
Probe Variants - parameters are as follows:
MICRO-SPECT-C1P MICRO-SPECT-C5P MICRO-SPECT-C20P MICRO-SPECT-C60P MICRO-SPECT-C500P MICRO-SPECT-C1600P
Detector Volume (mm³): 1 5 20 60 500 1600
Energy Resolution (%): <1.5 <1.5 <2.0 <2.0 <2.0 <3.0
Size (mm): 8 Ø x82 8 Ø x82 8 Ø x82 8 Ø x82 28 Ø x58 32 Ø x58
Weight (g): 80 80 80 80 80 80
Inbuilt Sensor Variants - parameters are as follows:
MICRO-SPECT-C1P MICRO-SPECT-C5P MICRO-SPECT-C20P MICRO-SPECT-C60P MICRO-SPECT-C500P MICRO-SPECT-C1600P
Detector Volume (mm³): 1 5 20 60 500 1600
Energy Resolution (%): <1.5 <1.5 <2.0 <2.0 <2.0 <3.0
Size (mm): 8 Ø x82 8 Ø x82 8 Ø x82 8 Ø x82 28 Ø x58 32 Ø x58
Weight (g): 80 80 80 80 80 80
MICRO-SPECT-S
Scintillator/SiPM-based Gamma-ray Microspectrometer has parameters as follows:
Scintillator Type/Size:
CsI(Tl) / 12.7 x 25.4 x 50.8mm
Detector Type/Size:
SiPM / 12.7 x 25.4mm
Energy Range:
20 keV to 3 MeV
Throughput (max.):
200 kcps
Energy Resolution:
<6.5%@662keV, <18%@59.5keV
Power/Signal:
USB (4.5 to 5.25V), 350mW
Size:
25 x 40 x 70mm
Weight:
145g
Operating Temperature:
-20deg.C to +50deg.C
WinSPEC
All MICRO-SPECT spectrometers are supplied with a user interface - WinSPEC - which is both robust and easy to use.
WinSPECMICRO-SPECT WinSPEC
